ASTRALLOY 2000 High Nickel Cast Iron Non-Conductive Flux
Very soft machinable welds on all weldable cast irons. Especially suited for welding in deep recesses or close quarters due to the non-conductive flux coating. Soft very machinable high nickel cast iron electrode featuring a totally non-conductive flux coating. Flux coating does not side arc even after being heated.
純鎳芯鑄鐵焊條,低溫碳稀釋少不龜裂,可車削,藥皮不導電,適用鑄鐵,鋼,鎳及鎳合金。
10 LB / BOX
==============================================================================================
ASTRALLOY 2600 Non-Machinable Cast Iron Non-Conductive Flux
For non-machinable welds on machine bases, furnace grates, exhaust manifolds, etc. Nickel free cast iron problem solver, seals in porosity generating contaminants prior to finish welding with nickels.
• Easily clads heat oxidized and oil impregnated castings
• Perfect color match to cast iron
• Non-conductive flux coating
不含鎳,適合被高溫燒過之鑄鐵,如:爐壁,排氣管等焊補。
===============================================================================================
ASTRALLOY 2900 Copper Clad Tri-Metal NonOverheating Cast Iron
The high deposition rate of this electrode creates an extremely narrow heat affected zone. This feature is suitable for all weldable cast irons that require post weld machining.
適用於各種鑄鐵斷裂焊接,非常好焊,可加工車削,可將鑄鐵與各種鋼材焊在一起。
====================================================================================================================
ASTRALLOY 3800 High Strength Self Fluxing 5% Silver Torch
Alloy for Copper to Copper
- Fabricate and repair copper air conditioning components, refrigeration components, radiators, heat exchangers, and other devices made from copper sheet and fittings. - Join copper bus bards, electrical conduit, cable, and fabricated copper vessels. - Join copper without flux in applications where flux is detrimental.
流動性好, 經高脫氧處理, 不會產生氣孔。焊接銅及銅合金。
===============================================================================================
ASTRALLOY 4000 5% Silicon Flux Coated Arc/Torch Aluminum Alloy
For arc welding aluminums alloyed with copper, silicon, and magnesium. Also excellent for joining dissimilar grades of aluminum. 5% Silicon aluminum arc welding electrode with exclusive self lifting slag. Other aluminum grades such as Al 99, Al Mn, etc. are also available.
特殊鋁合金焊條,可焊砂模鋁,模鑄鋁及各種鋁合金材質。
===================================================================================================================
ASTRALLOY 4100 A Rub-on Solder for Aluminum without Flux
Ideal for joining aluminum extrusions used in the manufacture and repair of aluminum doors and windows. Also for repairing leaders, gutters, siding, aluminum boats and instrument boxes. Most kirksite and zinc base die castings can be repaired with this alloy. Can also be used as a wearfacing alloy on aluminum.
高強度, 抗腐蝕, 色澤和鋁及鋁合金一致。不須使用焊劑, 低溫400℃以下就可使用, 非常方便、母材不變形.
===============================================================================================
ASTRALLOY 4400 Low Melting Aluminum Solder for Joining Aluminum to Itself and Other Metals
With a lower bonding temperature than silver brazing alloys, it is ideal as an intermediate alloy for joining. Excellent for low temperature joints on:
Aluminum tube, copper tube, and refrigeration and air conditioning units
Aluminum radiators
Sheet metal work
Manufacturing and repair of instruments
Zinc base die casting
Joining of dissimilar metals
Can also be used on anodized aluminum
對所有白色金屬, 包括鋅、錫鉛合金、鋁等有明顯的連接性能。它可以連接銅、青銅、黃銅、鋼、不銹鋼、鎂及相關合金。
連接不同金屬: 與不同的金屬具有良好的連接性, 包括鋁和銅或其它不同金屬的接合。
低溫操作: 在低溫179℃就可操作, 可使用電鉻鐵或火焰。這種低溫操作可防止金屬破壞和變形, 亦可使用TIG焊接。
==============================================================================================
ASTRALLOY 5000 Blue Mild Steel
Versatile all around repair and fabrication of clean, well fitting common mild steel components. Fast freeze slag characteristics ensures fully positional operability.
具有高拉力及降服強度可立焊、仰焊、使用方便。
焊道快速凝結。
優良機械加工性能, 焊條可以彎曲, 以便作難以接近位置之焊接。
容易使用, 電弧穩定。
藥皮含易電離材料, 電焊時產生霧狀金屬。
焊薄板用低電流, 不會燒穿。
===============================================================================================
ASTRALLOY 5100 7018 Moisture Resistant Low Hydrogen
For joining and repairing boiler plate, pipe steels, shipbuilding steels and cast steels. Excellent for weathering steels, such as "Corten".
交直流兩用於高張力鋼。
全方位操作。
優良機械加工性能, 焊條可以彎曲, 以便焊接難以接近的位置。
容易使用, 電弧穩定。
焊渣噴濺少, 焊道平整。
===============================================================================================
ASTRALLOY 5300 Extra High Strength Low Hydrogen
Structural and repair welds on high strength fine grained steels.
交，直流兩用於中低合金鋼。
超低濕氣含量，低於 .14 %。
全方位操作。
焊渣噴濺少，焊道平整, 無夾渣。
====================================================================================================================
ASTRALLOY 6000 Gold 312(29/9)
Due to exceptional strength and crack resistance, it is ideal for repairing tools, dies, spring steel and any dissimilar metal combinations, except for the aluminum and copper alloys. It is also recommended for repairing worn parts and as an underlay for hardfacing.
內含兩相微金屬組織、奧氏田體及飛來鐵組織。
抗拉強度極高、高延伸率、良好的耐熱性及加工硬化性, 越用越韌。
高韌性、高伸張度, 特別適用不同金屬的焊接。
對於敏感易裂舊焊道或受污染不潔之工件, 焊接效果最適宜。
可焊接高度耐震及耐衝擊之工件。
超高彎曲強度, 遠高於軟鋼電焊條的拉力。
低浸透及高合金含量, 使碳游離及淡化減至最低。
抗腐蝕力強, 比一些不銹鋼更佳。
===============================================================================================
ASTRALLOY 6600 316L-16
For molybdenum bearing stainless steels with 1.5 to 3.0% Mo. Primarily used for resistance to pitting, many acids and general corrosion.
含有特製的合金成份, 增強抵抗酸鹼, 焊接不產生氣孔, 強度高。
高延伸率, 特別適用在敏感易裂焊道的修護。
低含碳量, 可有效預防不鏽鋼, 如:200、304、308、316系列、400系列等。
適用於食品製造和飲料工廠和化學工廠。
可以維修所有的不銹鋼設備。
比普通不銹鋼焊條更具優良的抗腐蝕性, 含量極低的碳成份, 使其成為最佳的抗點蝕不銹鋼維修焊條。
===============================================================================================
ASTRALLOY 6905 Duplex 2209
For welding and cladding "DUPLEX" stainless sheets and castings. Universal "DUPLEX" electrode for welding and cladding of austenitic/ferritic microstructure stainlesses
具備了奧氏田鋼及鐵素體鋼(Austenitic / Ferritic)成份, 具高強度, 高延伸率。
焊道含氮元素, 能預防點蝕, 腐蝕及裂縫產生, 增強抵抗氯及鹽水腐蝕。
雙相不銹鋼最適合用在熱交換管, 油管, 氣槽, 防海水腐蝕。
可以維修所有的不銹鋼設備, 比304L, 316L不銹鋼有更好的耐蝕性, 抗裂性。
比普通不銹鋼焊條更具優良的抗腐蝕性, 含量極低的碳成份, 使其成為最佳的抗點蝕不銹鋼維修焊條。
===============================================================================================
ASTRALLOY 7000 Chromium Carbide
For protecting most iron base surfaces against severe abrasive wear and moderate impact. Chromium carbide electrode for economical smooth overlays
焊道金屬非常平滑, 極耐磨及衝擊。
形成均勻而穩定之微組織。
功能抵受嚴酷的磨擦, 因為它擁有堅硬的碳化鉻組織。
良好韌性、抗裂和耐磨性質的結合來自一種奧氏體結構及高硬度之碳化鉻麻田塞鐵。
===============================================================================================
ASTRALLOY 7300 M2 High Speed Tool Steel
For repair and reclamation of high speed cutting and machining tools. High hardness tool steel electrode for high speed tool steels
具有高硬度及高韌性切削性能。
在高溫情況下, 仍保有優異的性能。
適合焊接工具鋼、模具鋼、高速鋼。
=====================================================================================================================
ASTRALLOY 7310 Air Hardening Tool Steel Electrode
Ideal for repairing and rebuilding shear blades, percussion drills, earth borers, crusher jaws, etc. Unique alloy for repair & build-up of all Air Hardening tool steels
適用於各種熱作模具及空氣硬化, 如: 模具鋼的修護焊補, 特別是SKD 61。
只需使用低電流焊接, 減少母材晶相組織的破壞, 同時焊條熔解快速, 與母材親和力佳, 可減少氣孔的產生。
採空氣淬火的特性相當卓越。
可經熱處理改變焊道的硬度與特性。在高溫環境下, 仍保有相當好的熱作特性。
===================================================================================================================
ASTRALLOY 7400 Nickel Chrome Manganese High Recovery
For joining and repairing steel and manganese steel parts used throughout the railroad, construction, and related industries. Impact resistant electrode for joining and surfacing steels.
為抗衝撞之錳鎳鉻合金焊條, 有很強的結合力及韌性。
能快速工作硬化從焊接時RC10迅速硬化至RC50, 深層硬化。
高結合力及延伸率, 不但可以做接合用, 更是最理想之耐衝撞、耐磨錳鋼焊條。
===============================================================================================
ASTRALLOY 7600 All Position Shock and Abrasion Resistance
Excellent for restoring worn hammers and assorted parts in rock crushing equipment. All position shock and abrasion resistant electrode
為抗衝撞、耐磨之合金焊條, 有很強的韌性。
高結合力, 為最理想之耐撞擊、耐磨焊條。
可一層又一層的堆焊, 不會龜裂或脫落。
=====================================================================================================================
ASTRALLOY 7700 RC-67 Niobium Carbide
For protecting all iron based parts subject to severe fine particle abrasion. Also excellent in wear applications at elevated temperatures. Smooth deposits enriched with Niobium Carbide and Chromium Carbide offer the ultimate combination of abrasion resistance and high temperature hardness retention
含鈮碳化合物、碳化鉻之極耐磨、耐高溫之焊條。
硬度可達RC 64-68, 耐溫至1600℉(870℃)。
用於抗砂磨及高溫之場所最好焊條。能抵受想像得到最厲害之磨擦。在有些場合《阿斯特勒 7700》可用以取代高價之 Stellite
=====================================================================================================================
ASTRALLOY 7710 Tubular Tungsten Carbide
Ideally suited for overlaying mining and earth moving equipment.Excellent for wire saws and other edges requiring cutting action combined with abrasion resistance. Tungsten carbide overlay within a high carbon steel matrix
熔著金屬內有大量之碳化鎢合金。
硬度極高, 最具抗磨損性能。當一個碳化物被破壞, 另一個取代它。
因此焊道會自我銳化, 也適用在切削和鑽孔中。
可抵受砂磨和石磨中最嚴重的研磨類磨蝕作用。
以合金鋼管代替了低碳鋼管, 用一種獨特的碳化鎢填充。
=====================================================================================================================
ASTRALLOY 7900 High Recovery Inconel 625 (112) Electrode
For joining and cladding most nickel alloys, stainless steels, and carbon steels. Excellent for oxidation and corrosion resistant applications. Inconel 625 electrode that performs on AC current as well as DC current
具有非常良好的抗裂強度及抗裂性能, 及在高溫下優異之抗氧化、抗腐蝕之特性。
為高鎳質如莫涅耳(MONEL)及因科鎳(INCONEL)之理想焊條。
防熱耐熱能高至1050℃, 低溫至 -96℃。適用於燃燒系統設備。
具時效硬化的特性。
高密度無氣孔的焊層。
=====================================================================================================================
ASTRALLOY 7920 Crack & Corrosion Resistant 112 Nickel Base Alloy
Phenomenal strength and crack resistance
Excellent positional performance
Weld metal is highly corrosion resistant
Used extensively in the petrochemical industries
耐高溫、低溫及耐腐蝕。
在高溫下具有非常良好的抗氧化、抗腐蝕與優異的抗裂強度及性能。
具有高延伸率及高強度, 焊渣容易清除。
全方位焊接, 含鈮。
=====================================================================================================================
ASTRALLOY 7930 Hastelloy C Electrode High Recovery
Ideally suited for applications involving both heat and corrosion, joining dissimilar nickel alloys or joining these alloys to the stainless steels. For fabrication and repairing chemical vats, retorts, valves and valve bodies, plating tanks, racks and supports, chemical pipelines, evaporators, digestors, hot-work forging dies, furnace racks, hoods and baffles, pumps, valves and controls.
含高成份之鎳鉻鉬及其他特殊元素。
高韌性、高伸張度, 特別適用於不同金屬之焊接。
具有最好的耐酸、鹼及抗高溫之特性。
最適合化學工業設備, 如: 管路、反應桶、幫浦等焊接維修。
為熱鍛造模具、爐具等理想之維修焊條。
====================================================================================================================
ASTRALLOY 8000 "Magic Metal" Bronze Filled Epoxy Stick
A metallic resin that hardens into a tough alloy without any need for measuring its two components
不生銹，不氧化，耐腐蝕性及耐化學。
不具磁性，不導電，可以在儀表上使用。
迅速定型，一小時即硬化，可加工或鑽孔。
快速修補管路或容器的破裂處，不須電流或火焰。
=====================================================================================================================
ASTRALLOY 8400 Solid Core Silver Bearing Soft Solder
A very high strength lead and cadmium free soft solder that is FDA approved.
物理性能高,拉力高達18,000psi (12.6kg/㎜2),超越普通焊料, 最適宜薄小零件的焊接。
導電能力比一般焊料如錫鉛焊料高。
再熔溫度比一般焊料高。
符合所有純食物法例, 不含鉛、鎘或其它有毒或有害的金屬。抵抗腐蝕的低熔點合金。
主要用於不銹鋼及不同金屬之焊接, 具有卓越的抗腐蝕性。
熔點215℃。
=====================================================================================================================
ASTRALLOY 9000 Green Turbo-Blast Chamfering/Cutting
Can gouge, bevel or cut all metals including stainless steels, aluminums and copper. Excellent for the removal of stainless steel joints and overlays. No oxygen is required. Chamfering/cutting electrode with 25% more arc blast force
特殊的焊芯及藥皮可在高電流下使用而不過熱, 能在焊條前端產生強力的噴射氣體, 吹走熔化的金屬, 而得到一個清潔, 乾淨的U型槽。最適合去除舊焊道、難溶的金屬、焊接前切邊與修整之用。
可以切割所有金屬(除鎂之外), 包括不銹鋼、銅、鋁、合金鋼等。
===============================================================================================
ASTRALLOY 9500 56% Silver Flux Coated Pink
For color matching stainless steel and for low temperature high strength joints in the food, medical and pharmaceutical industries. Super active flux coated cadmium free silver brazing alloy with 56% silver content
溶點低、流動性良好, 604℃~640℃, 該溫度不會太高而導致焊件變形翹曲。
耐腐蝕佳。
不含鉛、鎘或有害金屬。
適用於絕大部份的維修。它能焊接幾乎所有的金屬, 包括鎳鉻鐵合金、蒙乃爾高強度耐蝕鎳銅合金、銅、黃銅、鋼、不銹鋼 (除了白色金屬以外, 如: 鋁、鎂), 用在修補不銹鋼網上尤其好用。對食品和衛生用具也非常適合, 適合醫院和儀器, 不會像普通焊條出現鎘毒所產生的危害。
=====================================================================================================================
ASTRALLOY 9700 Blue Low Fuming Bronze – No Glare Flux
Torch brazing most steels and cast irons. Especially suited for joining thin sections. Triple deoxidized bronze brazing alloy with "Safe Vue" moisture sealed flux coating
藥皮經過防潮處理, 不會潮濕、不脫落。
對鑄鐵、碳鋼、合金鋼、銅、青銅、黃銅都有很高的親和力。
可焊接所有不同金屬的接合(除白色金屬以外)。
對薄板焊接也不會燒穿。
=====================================================================================================================
ASTRALLOY 9800 Red Nickel Silver – No Glare Flux
High strength joining of steels using both the thin flow and bead form techniques. Ultra high purity nickel silver alloy featuring "Safe Vue" moisture sealed flux coating
含鎳合金, 高抗拉強度。
藥皮經過防潮處理, 不會潮濕、不脫落。
對鑄鐵、碳鋼、合金鋼、銅、青銅、黃銅都有很高的親和力。
可焊接所有不同金屬之接合 (除白色金屬以外)。
對薄板焊接也不會燒穿。
